Vishay / Spectrol Model 357 1k 2k 5k 10k Bushing Mount Rotary Potentiometers

Quick Detail

• 7/8" diameter single turn.
• Compact size, advanced design technology.
• Offer a cost effective solution to your potentiometer requirements.
• Suitable model for all industrial applications.
• Conductive plastic element.
• Nominal resistance range 1 kΩ to 50 kΩ, tolerance 20%,10% can be customised.

• Power rating 1W at 70 °C.

• Linearity 2.0%, 1.0% can be customised.

Description

The WI27 Conductive Plastic Potentiometer is a high-quality, single-turn potentiometer designed for precise control in various applications. Featuring a compact 7/8" (22.2 mm) bushing mount type, this potentiometer is both versatile and easy to install. It offers a nominal resistance 5kΩ, with a power rating of 1 watt at 70°C. The resistance tolerance is ±20%, with the option to customize to ±10% for specific needs.

The WI27 potentiometer is engineered for accuracy, boasting an independent linearity of ±2.0%, which can be customized to ±1.0% for even greater precision. Its electrical travel is 340° ± 3°, ensuring smooth and reliable operation within its specified range. This conductive plastic potentiometer is ideal for applications requiring dependable and precise adjustments.

Specification

Dimension

Dimensions in mm, tolerances ±0.30 mm unless otherwise specified.

Application

The WI27 conductive plastic potentiometer is a versatile component used in various applications due to its precision and reliability.

1. Industrial Automation
- Used in control systems for precise positioning and movement.
- Common in robotic arms and CNC machinery.

2. Automotive Industry
- Utilized in throttle position sensors, pedal position sensors, and steering angle sensors.
- Helps in achieving accurate control of engine and transmission systems.
3. Medical Equipment
- Employed in medical devices such as infusion pumps, ventilators, and imaging equipment.
- Ensures precise control and measurement of critical parameters.
4. Aerospace and Defense
- Used in flight control systems, navigation instruments, and weapon control systems.
- Provides reliable performance in harsh environments.
5. Consumer Electronics
- Found in audio equipment, gaming devices, and home automation systems.
- Enhances user interface with precise control over volume, tuning, and other settings.
6. Test and Measurement Equipment
- Integral to devices like oscilloscopes, signal generators, and multimeters.
- Ensures accurate measurement and calibration.
7. Renewable Energy Systems
- Applied in wind turbine control systems and solar tracking systems.
- Optimizes the efficiency of energy generation.
8. Marine and Offshore
- Used in navigation systems, engine control systems, and winch control.
- Ensures reliable operation in marine environments.

Advantage

• Factory direct supply, no middlemen.
• Completed certificates such as RoHS, REACH, etc and best quality assurance.
• Sufficient production capacity, short delivery time.
• Professional after-sales service team.
• OEM & ODM available.
