3362P 0.5W 100K Adjustable Resistance Single Cermet Trimmer Trimming Potentiometer
The 3362P trimmer potentiometer is a compact and precise electronic component used for adjustable resistance in various applications. Its small size allows for easy installation even in limited space. With high precision and stability, it provides accurate and reliable resistance adjustments. The 3362P trimmer potentiometer is commonly used in audio equipment, consumer electronics, and communication devices.
| Electrical Characteristics | Resistance Range | 10Ω-5MΩ |
| Resistance Tolerance | ±10% ；±20% | |
| Terminal Resistance | ≤±1%R or 3Ω | |
| Contact Resistance Variation (CRV) | ≤3%R or 3Ω | |
| Insulation Resistance | 500 Vdc. 100 megohms min. | |
| Withstand Voltage | 101.3KPa,500 Vac；8.5KPa,250 Vac | |
| Dielectric Strength | 500 Vac(1 Min.) | |
| Electrical Travel | 220° | |
| Environment Characteristics | Weld Heat Resistance | 250℃ ,10 Secs. |
| Rated Power(300 volts max.) | 70℃,0.5W；125℃,0W | |
| Temperature Range | -55°C ~ + 125°C | |
| Temperature Coefficient | ±250,±100 ppm /°C | |
| Temperature Variation | ΔR≤±3%R, Δ(Uab/Uac)≤±1% | |
| Collision | 20G, ΔR≤±1%R, Δ(Uab/Uac)≤±1% | |
| Vibration | 100G, ΔR≤±1%R,Δ(Uab/Uac)≤±2% | |
| Electrical Endurance At 70°C | 1000 hours @ 70℃ Rated Power; ΔR≤±3%R | |
| Rotational Life | 200 Cycles,ΔR≤±3%R | |
| Physical Characteristics | Total Mechanical Travel | 250° |
| Starting Torque | ≤25 mN.m | |
| Clutch Torque | ≤35 mN.m |
packaging specification: 50 pieces/tube.
■ Electronics Manufacturing
It is commonly used in the production of audio equipment, consumer electronics, and electronic devices where precise resistance adjustments are required.
■ Circuit Prototyping
The 3362P trimmer potentiometer is frequently utilized in circuit prototyping and testing for fine-tuning resistance values.
■ Industrial Controls
It finds applications in industrial control systems, allowing for accurate resistance control in automation and machinery.
■ Robotics
The 3362P trimmer potentiometer is employed in robotics applications for precise adjustments in motor control circuits.
■ Instrumentation
It is used in the design and calibration of measurement and testing instruments, ensuring accurate resistance values for precise measurements.
■ Automotive Electronics
The 3362P trimmer potentiometer is utilized in various automotive electronic systems, including vehicle controls, infotainment systems, and engine management.
■ Telecommunications
It finds application in telecommunications equipment for precise resistance adjustments in signal processing circuits.
■ Medical Devices
The 3362P trimmer potentiometer is used in the manufacturing of medical devices, such as patient monitoring systems and diagnostic equipment.
■ Aerospace & Defense
It has applications in aerospace and defense systems, including avionics, navigation systems, and communication equipment.
